Lewis AE Axial Cylinder 4 Pistons Hydraulic Disc Brake

The AE brake lever features a completely new feel tuning, providing a firmer and more substantial sensation compared to the LH series. It is better suited for riders who prefer a higher feedback force from the brake lever.

The AE brake uses Lewis's latest integrated CNC caliper, offering higher caliper rigidity, longer maintenance intervals, and extended lifespan.

AE brakes are made of aerospace-grade 7075 aluminum, which are cut and formed by CNC high-precision, with high strength and light weight.

Single brake lever weight: 112g;  Single caliper weight: 108g

The 14mm + 17mm asymmetric piston design enhances brake linear feel, ensures even brake pad pressure distribution, and balances wear.

Up to four precision bearings make up the pivot point of the brake lever, providing riders with an exceptional braking experience down to the finest details.


Retail Price: US$225 per set (Front +Rear Brakes),Tax Excluded



Worldwide Dealers Wanted

For purchasing more matching brakes, please click on "Inquire now" to leave us a message.

Inquire now
Add to cart
Share To:
Technology
  • New Split clamp
    New Split clamp

    Higher strength, more portable.

  • Brake lever reach adjustment
    Brake lever reach adjustment

    Rotate the brake lever reach knob to adjust the lever reach.

  • Up to four precision bearings
    Up to four precision bearings

    Each movable pivot is secured by two precision bearings, totaling four bearings, ensuring stability and smooth operation without play.

  • One Body Caliper
    One Body Caliper

    In a high-pressure hydraulic environment, the caliper deformation is minimal, resulting in more stable braking performance.

SPECIFICATIONS
MASTER CYLINDER
TypeAxial
Material 7075 aluminum
Body Finish Black
Clamp Color Black
Clamp Type Split
ScrewsStainless Steel
ADJUSTABLE LEVER REACHYES, Tool Free




LEVER BLADE
Material 7075 Aluminum
Color Black
Brake lever version1 Finger


CALIPER
Material 7075 Aluminum
Color Black
MOUNT TYPEPost mount
Piston 2 x 14mm + 2 x 17mm  Stainless steel Pistions
ScrewsStainless Steel
Pad type Metallic


Hose
Hose size Outside Diameter 5mm,Bore 2.2mm
Hose length 90cm front /160 cm rear, can be shorten to adapt bike
Hose finish Black, Braided T200 Oil Hose
INTENDED USEEnduro, Downhill, All-Mountain
Rotors Not included, optional (140 mm | 160 mm | 180 mm | 203 mm | 223 mm)
AdapterNot included
WEIGHTSingle brake lever : 112g;  Single caliper: 108g
OilMineral oil
Bleed Kit RecommendationEZMTB 2022std
